Appendix
Code table
10
l
87
LDEDS−CCU210B EN 4.0
10.2 Code table
How to read the code table
Column Abbreviation Meaning
Code
No.
Cxxxx Code No. Cxxxx
1 Subcode 1 of Cxxxx
2 Subcode 2 of Cxxxx
[PWD] Code can only be altered after the service password has been entered in
C0007.
ñò
Access to the code
RW Read and write
R Read only
<
Memory location
INT Internally in the Flash memory
EXT Externally in the data connector
Byte
Data length in bytes
Possible settings
Lenze
Setting at delivery
Setting after loading the Lenze setting with C0002 = 1
Selection 1 {%} 99 Minimum value {Unit} Maximum value
Description
Short description of the code
Code Possible settings Description
No. ñò < Byte Lenze Selection
C0002 RW 4 0
Parameter set management
1 Load Lenze setting
2 Reserved
3 Write all parameters in EEPROM
C0003
[PWD]
RW INT 4 1
Storage method for parameters
0 Do not save parameters in EEPROM
1 Save parameters in external EEPROM
2 Save parameters in internal EEPROM
C0006 RW EXT 4 0
Parameter version, freely available
for users
0 255
C0007 RW 4 0
Password (PWD)
0 65535
C0010 RW EXT 4 10000
Conversion factor: speed at 50 Hz
drive frequency
^ 52
0 {mm/min} 65535
