Function library
Digital input signals
Connection logic
8
l
45
LDEDS−CCU210B EN 4.0
Codes for parameter setting
Code Possible settings Description
No. ñò < Byte Lenze Selection
C0409 Logic operations of digital input
signals
Link ORx = OR operation
Link ANDx = AND operation
^ 44
1
RW EXT 2
0
0 65535
Link OR1
2 0 Link OR2
3 0 Link OR3
4 0 Link OR4
5 0 Link OR5
6 0 Link OR6
7 0 Link OR7
8 0 Link OR8
9 0 Link AND1
10 0 Link AND2
11 0 Link AND3
12 0 Link AND4
13 0 Link AND5
14 0 Link AND6
15 0 Link AND7
16 0 Link AND8
Possible values
Add values of the digital input
signals to define a linkage:
e. g. DIN1, SS1 full−wave and SS2
full−wave are to be assigned to link
OR2 (OR operation)
à C0409/2 = 17409.
0 No linkage
1 DIN1
2 DIN2
4 DIN3
8 DIN4
16 DIN5
32 DIN6
64 DIN7
128 DIN8
256 SS1 positive half wave
512 SS1 negative half wave
1024 SS1 full−wave
2048 Reserved
4096 SS2 positive half wave
8192 SS2 negative half wave
16384 SS2 full−wave
31768 Reserved
