Function library
Digital input signals
Assignment logic
8
l
47
LDEDS−CCU210B EN 4.0
DescriptionPossible settingsCode
SelectionLenzeByte<ñòNo.
C0410 (Continuation)
Linking digital input signals to an
internal device function ...
^ 46
Possible values
0 Not assigned
1 DIN1 Digital input DIN1
2 DIN2 Digital input DIN2
3 DIN3 Digital input DIN3
4 DIN4 Digital input DIN4
5 DIN5 Digital input DIN5
6 DIN6 Digital input DIN6
7 DIN7 Digital input DIN7
8 DIN8 Digital input DIN8
9 SS1 positive half wave Control bar 1 positive half wave
10 SS1 negative half wave Control bar 1 negative half wave
11 SS1 full−wave Control bar 1 full−wave
12 Reserved
13 SS2 positive half wave Control bar 2 positive half wave
14 SS2 negative half wave Control bar 2 negative half wave
15 SS2 full−wave Control bar 2 full−wave
16 Reserved
... ...
31 Reserved
32 Link OR1 Result of OR operation 1
33 Link OR2 Result of OR operation 2
34 Link OR3 Result of OR operation 3
35 Link OR4 Result of OR operation 4
36 Link OR5 Result of OR operation 5
37 Link OR6 Result of OR operation 6
38 Link OR7 Result of OR operation 7
39 Link OR8 Result of OR operation 8
40 Link AND1 Result of AND operation 1
41 Link AND2 Result of AND operation 2
42 Link AND3 Result of AND operation 3
43 Link AND4 Result of AND operation 4
44 Link AND5 Result of AND operation 5
45 Link AND6 Result of AND operation 6
46 Link AND7 Result of AND operation 7
47 Link AND8 Result of AND operation 8
48 Reserved
... ...
63 Reserved
