12
ENGLISH
Commissioning
Code Possible Settings
IMPORTANT
No. Name Lenze Selection
Password entry
0
0 999 Visible only when password is active
(see C94)
1
Setpoint and control
source
0
Setpoint source: Control configuration:
0 Analog input (8U / 8I; see C34) Control = terminals
Programming = keypad
Monitoring = LECOM
1 Code c40 / Code C47
2 Analog input (8U / 8I; see C34) Control = terminals
Programming = LECOM / keypad
Monitoring = LECOM
3 LECOM Control = LECOM
Programming = LECOM / keypad
Monitoring = LECOM
4 Analog input (8U / 8I; see C34) Control = terminals
Programming = remote keypad
Monitoring = remote keypad
5 Code c40 / Code C47
6 Analog input (8U / 8I; see C34) Control = remote keypad
Programming = remote keypad
Monitoring = remote keypad
7 Code c40 / Code C47
8 Analog input (8U / 8I; see C34) Control = terminals
Programming = Modbus / keypad
Monitoring = Modbus
9 Code c40 / Code C47
10 Analog input (8U / 8I; see C34) Control = Modbus
Programming = Modbus / keypad
Monitoring = Modbus
11 Code c40 / Code C47
Note
• When C01 = 1, 5, 7, 9, or 11 and C14 = 0...4, 6, 7, use c40 for speed setpoint
• When C01 = 1, 5, 7, 9, or 11 and C14 = 5, use C47 for torque setpoint
• When C01 = LECOM (3), write speed command to C46 or torque command to C47.
Load Lenze setting 0 No action/loading complete • C02 = 1, 2, 3 only possible with
or
• C02 = 2 : C11, C15 and C89 = 60 Hz
and C87 = 1750RPM
1 Load 50 Hz Lenze settings
2 Load 60 Hz Lenze settings
3 Load OEM settings (if present)
WARNING!
C02 = 1...3 overwrites all settings! TRIP circuitry may be disabled!
Check codes CE1...CE4.
4.3 Parameter menu
