19
ENGLISH
Commissioning
Code Possible Settings
IMPORTANT
No. Name Lenze Selection
7
Conguration TRIP
reset (error reset)
0 0 TRIP reset after LOW-HIGH change at
terminal 28, mains switching, or after
LOW-HIGH change at digital input
“TRIP reset”
1 Auto-TRIP reset • Auto-TRIP reset after the time set in c71
• More than 8 errors in 10 minutes will
trigger
S fault
WARNING!
Automatic starting/restarting may cause damage to equipment and/or injury to personnel!
Automatic starting/restarting should only be used on equipment that is inaccessible to
personnel.
7
Auto-TRIP reset delay 0.0 0.0 {s} 60.0 See c70
7
Input voltage selection 0 Low (for 200 or 400 V input) • Lenze setting depends on C93
• During commissioning, conrm
correct setting based on mains voltage
1 High (for 230 or 480 V input)
7
Operating time counter Display
Total time in status “Start”
0...999 h: format xxx
1000...9999 h: format x.xx (x1000)
10000...99999 h: format xx.x (x1000)
7
Mains connection time
counter
Display
Total time of mains = on
S-ramp integration
time
0.0 0.0 {s} 50.0 • c82 = 0.0: Linear accel/decel ramp
• c82 > 0.0: Adjusts S-ramp curve for
smoother ramp
Skip frequency 1 0.0 0.0 {Hz} 240 • L25 and L26 dene the start of the skip
range
• L28 denes the bandwidth of the skip
range
Skip frequency 2 0.0 0.0 {Hz} 240
Skip frequency
bandwidth
0.0 0.0 {Hz} 10.0
Note
Bandwidth (Hz) = fs (Hz) + L28 (Hz) fs = L25 or L26
Example: L25 = 18 Hz and L28 = 4 Hz; the bandwidth = 18...22 Hz
LECOM power up
state
0 0 Quick stop
1 Inhibit
Serial time-out action 0
0 Not active
Selects controller reaction to serial timeout
1 Inhibit
2 Quick stop
3 Trip fault
Serial fault time 50 50 {ms} 65535 Sets the serial timeout length
