Mounting
Leuze electronic BPS 34 39
TNT 35/7-24V
Figure 7.2:BT 56 mounting device
Clamping jaws for
mounting on the BPS
Clamp profile for
mounting to round or
oval pipes
Ø16…20mm
A Rod holder, turnable 360°
B Rods Ø 16 … 20mm
all dimensions in mm
