Technical data of BPS 34
14 BPS 34 Leuze electronic
4 Technical data of BPS 34
4.1 General specifications BPS 34
Optical data
Light source Laser diode
Beam deflection Via rotating polygon wheel
Reading distance See reading field (Figure 4.3.5)
Optical window Glass with scratch-resistant indium coating
Laser class 2 acc. to IEC 60825-1:2007
Wavelength 655nm
Max. output power (peak) 1.8mW
Impulse duration 120µs
Measurement data
Reproducibility (3 sigma) -1 mm
Response time 16ms (configurable)
Output time 2ms
Basis for contouring error cal-
culation
7ms
Working range 90 … 170 mm
Max. traverse rate 10m/s
Electrical data
Interface type PROFIBUS DP, up to 12MBd
Service interface RS 232 with default data format,
9600Bd, 8 data bits, no parity, 1 stop bit
Switching input / switching out-
put
1 switching input, 1 switching output, each is
programmable
Green LED Device ready (power on) and bus O.K.
Operating voltage Without optics heating: 10 … 30VDC
With optics heating: 22 … 26VDC
1)
Power consumption Without optics heating: 5W
With optics heating: max. 30W
Mechanical data
Degree of protection IP 65
2)
Weight Without optics heating: 400g
With optics heating: 480g
Dimensions (H x W x D) Without optics heating: 120 x 90 x 43mm
With optics heating: 120 x 90 x 52mm
Housing Diecast aluminum
Environmental data
Operating temperature range Without optics heating: 0°C … +40°C
With optics heating: -30°C … +40°C
High temperature version: 0°C … +50°C
Storage temperature range -30°C … +60°C
Air humidity Max. 90% rel. humidity, non-condensing
