Fast commissioning steps at a glance
Leuze electronic BPS 34 13
TNT 35/7-24V
Connecting the MSD 1 101 modular service display
The MSD 1 101 is connected via cable KB 034-2000 (M12 connection on MSD and M12
connection on MSD 1 101, see chapter 10.3 "Accessories - Modular service display" on
Page 95).
Figure 3.7:BPS 34 with MS 34 103/MS 34 105 - MSD connection
The BPS 34 can be accessed via the MS 1 101 using the service interface.
Note!
Changes which were made via the service interface on the BPS 34 are lost following initial-
ization on the PROFIBUS.

Socket
(A-coded)
Socket
(A-coded)
Socket
(B-coded)
Plug
(B-coded)
Plug
(A-coded)
1
2
3
4
MSD
5
6
7
/SERV
VIN
TXD
RXD
SCL
SDA
GND
/INT
PWR IN
SWIN
SWOUT
3
2
1
4
GND VIN
PE
SW IN/OUT
1
2
3
4
VOUT
PE
SWIN
SWOUT
GND
DP IN
GND
3
2
1
4
PE
A (N)
B (P)
VCC
DP OUT
VCC
1
2
3
4
A (N)
B (P)
GND
PE
