Device parameters and interfaces
Leuze electronic BPS 34 57
TNT 35/7-24V
8.1.7.5 Module 5: Offset value
Note!
Underlined in the CR column are the modules which must be activated in addition to the cur-
rent module.
Description
This module adds an offset value to the tape value.
Parameters
Note!
If module 3 "Static preset" or module 4 "Dynamic preset" is activated and, as a result, a new
value assigned to the tape value, the offset function no longer affects the position value. The
offset is not reactivated until the preset function (static and dynamic) is canceled. The offset
value is entered in mm. When entering the offset value, the scaling in module 6 must be
taken into account.
Hex coding of module 5 "Offset value"
The value listed in the table shows the hex coding of the default settings.
Input data
None
Output data
None
Parameter Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Offset
value in
[mm]
Offset value added to tape value 0 sign32 -10,000,000 … 10,000,000 0 mm 1
Parameter length: 4 byte
a
Internal address of module 5 Offset value
09 00 00 00 00
