8.1.7.17 Module 16: Dynamic position limit value 1
Description
The limit value function compares the position value with a stored position. If the value is
above or below the limit value, the limit value status 1 in module 12 is set and, if configured,
the switching output is appropriately set.
The limit value is transferred to the BPS 34 together with the output data of this module by
the PROFIBUS master.
Parameters
Hex coding of module 16 "Dynamic position limit value 1"
The value listed in the table shows the hex coding of the default settings.
Input data
None
Output data
Parameter Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Limit value
mode 1
Parameter activates the limit
value check.
0
unsign
8
0: Off
1: On
0 –7g
Switching
type 1
Condition for the signal change
of the switching output/status bit.
1
unsign
8
0: Value greater than limit
1: Value less than limit
0 –
8d
12e
Hysteresis
1 in [mm]
Relative offset of the switching
point.
2
unsign
16
0 … 65,535 0 mm –
Parameter length: 4 byte
a
b
c
Internal address of module 16 Limit value mode 1 address 0 Switching type 1 address 1 Hysteresis 1 address 2
0 F 00 00 00 00
Output
data
Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Limit value
1 in [mm]
Limit value is compared to the
current position value.
0 sign32 -10,000,000 … 10,000,000 0 mm –
Output data length: 4 byte
d
