5.3.8 Application
The IP Camera equips one alarm input and one relay output for cooperating
with alarm system to catch events’ images. Refer to alarm pin definition below to
connect alarm devices to the IP Camera if needed. The alarm configuration
page is also shown below.
Alarm Switch
The Administrator can enable or disable the alarm function.
Alarm Type
Select an alarm type, “Normal close” or “Normal open,” that corresponds with
the alarm application.
Alarm Output
Define alarm output signal “high” or “low” as the normal alarm output status
according to the current alarm application.
Triggered Action (Multi-option)
The Administrator can specify alarm actions that will take when the alarm is
triggered. All options are listed as follows:
