User Manual for LEVIFLOW
®
LFS-SU Flowmeters
www.levitronix.com
PL-4509-00, Rev09, DCO# 21-230
12
2.5.3 Dimensions of Adaptor Cables
Figure 11: Dimensions of wall mountable extension cable LFE-C.2
(Can be used for electrical cabinet mounting. Minimum bending radius > 10 x cable radius)
Figure 12: Dimensions of interconnect cable LFI-C.1
(Minimum bending radius > 10 x cable radius)
Connector
Hirose Plug Male
HR30-6P-6P
Connector
Hirose Plug Female
HR30-6P-6S
Length = 3m
Mounting Wall
Sealing Gasket
Wall-mountable Adaptor
Converter
Connector
Mounting Panel Dimensions
Length = 1,3,6 m
Delivered with protective
dust cap on connector)
