3.2 Installation of Converter LFC-6CIO-PC
3.2.1 Overview and Preparation
Figure 16: Multi-channel controller LFC-6CIO-PC
Fixation Bars
(un-locked)
Fixation Bars
(un-locked,
on both sides)
Connector Box
Termination
Box
EMI Ferrite
Zeroing
Botton
Channel Select 1-6
Address Setting for RS485:
High Adrs Low Address
4 Digit LED Display
Channel Indication 1-6
Bus Connector:
Pin #1
Pin #7
Sensor
Connectors:
Channel #6
Channel #1
Connector
Analog Output
Connector
Digital I/O
Connector
Analog Output
Connector
Digital I/O
Fixation Bars
(locked)
Fixation Bars
(locked on both sides)
