User Manual for LEVIFLOW
®
LFS-SU Flowmeters
www.levitronix.com
PL-4509-00, Rev09, DCO# 21-230
24
4.2.4 Operation with Levitronix
®
Service Software
For debugging, data collection and configuration of the flowmeter system the Levitronix
®
Service Software is
available at Levitronix
®
. Contact Levitronix
®
for a sample of the configuration software and the according
manual (see reference on title page of this manual). An approved USB to RS485 adaptor with the according
connection cable can be ordered according to the information in Table 3.
Figure 23: System operation with Levitronix
®
Service Software
4.2.5 Operation with RS485
Operation from a mother system with communication over an RS485 bus is possible. The according MODBUS
protocol can be requested at Levitronix
.
Single-Channel Converter LFC-1C-PC
4-Digit Display
Zero Adjustment
Adress Setting for RS
485
Piezo Transducers
In-/Output
Electrical Interface
Power Supply: 24 VDC
RS485
(MODBUS)
Analog and
Digital Outputs
- 1x Analog Output
- 2x Digital Outputs
- 1x Digital Input
Digital
Signal Processor
DSP
BUS
Converter
RS232/RS485
or
USB/RS485
Levitronix
®
Service Software
RS232 or USB
Other RS485
Devices
Adaptor/Extension Cable
Wallmountable connector
for cabinet mounting
Interconnect Cable
Various lengths.
Direct connection possible.
LEVIFLOW
®
Single
-Use Sensor LFS
-xxSU
Flow Out
Flow In
Connector
Box
EMI Ferrite
