Hazardous voltage may be present.
In order to avoiding fluid spills shorting voltages within the converter,
place it in a spill protected environment (for example protected electronic
cabinets).
If explosive flammable gases are present, place the converter in an
explosion-proof cabinet.
1. The converter shall be installed in a spill protected cabinet.
2. Assure that enough ventilation is provided in order to avoid exceeding the allowed ambient
temperature and humidity range specified in Table 5:
3. Bring the fixation bars in to un-lock position (see Figure 16).
4. If multiple converters are used (see Figure 16) stack them together.
5. Attach the connector box (see Figure 16)
6. Attach the termination box (Figure 16) and fix it by pushing the fixation bars of the termination
box (see Figure 16) to the inside.
7. Bring the fixation bars into the locked position (see Figure 16)
8. Mount the whole stack on a DIN rail following the same steps as described in Figure 15 for the
single channel converter LFC-1C-PC.
