Lexicon 960L Service Manual

Lexicon
8-3
PART NO. DESCRIPTION QTY EFF■INACT REFERENCE
240-12136 CAPSM,ELEC,33uF,10V,20% 5 C4,8,13,17,2O
240-13216 CAPSM,ELEC,22uF,16V,20% 5 C6,10,15,19,22
245-10416 CAPSM,CER,1000pF,50V,COG,5% 1 C1
245-12485 CAPSM,CER,.1uF,25V,Z5U,20% 12 C2,3,5,7,9,11,12,14
C16,18,21,23
330-10527 ICSM,DIGITAL,74HC138,SOIC 1 U1
500-13907 CONN,EURO,C,96P,abc,RECP,VERT 5 J1-5
510-13877 CONN,POST,.100,HDR,2X5MCG,LP 2 J6,7
510-13942 CONN,POST,.100,HDR,2X20MCG,LP 2 J10,11
510-13993 CONN,POST,.100,HDR,2X8MCG,LP 1 J8
510-13994 CONN,HDR,.200,4MC,SHRD 1 J9
I/O CLK BD ASSY,960L
202-09795 RESSM,RO,5%,1/10W,2.2K OHM 3 R19,22,25
202-09873 RESSM,RO,5%,1/10W,10K OHM 5 R2-4,27,30
202-09897 RESSM,RO,5%,1/10W,470 0HM 1 R5
202-09899 RESSM,RO,5%,1/10W,47 OHM 2 R1,16
202-10557 RESSM,RO,5%,1/10W,4.7K OHM 5 R26,28,29,31,32
202-10558 RESSM,RO,5%,1/10W,47K OHM 3 R6,14,15
202-10559 RESSM,RO,5%,1/10W,100 OHM 1 R13
202-10947 RESSM,RO,5%,1/10W,680K OHM 1 R10
202-11072 RESSM,RO,5%,1/4W,220 0HM 5 R18,20,21,23,24
202-11073 RESSM,RO,5%,1/4W,270 OHM 1 R17
203-10424 RESSM,RO,1%,1/10W,4.99K OHM 4 R7-9,11
203-10895 RESSM,RO,1%,1/10W,681 OHM 1 R12
240-09786 CAP,ELEC,100uF,25V,RAD,LOW ESR 2 C13,16
240-10758 CAPSM,ELEC,1uF,50V,20%,5.5mmH 2 C8,20
240-13217 CAPSM,ELEC,47uF,16V,20% 2 C22,23
241-09798 CAPSM,TANT,10uF,10V,20% 1 C26
244-10423 CAP,MYL,.22uF,50V,RAD,5%,BOX 4 C9,12,14,17
245-09869 CAPSM,CER,.001uF,50V,Z5U,20% 2 C48,51
245-09895 CAPSM,CER,10pF,50V,COG,10% 1 C35
245-10561 CAPSM,CER,100pF,50V,COG,5% 4 C41-44
245-10562 CAPSM,CER,150pF,50V,COG,10% 4 C10,11,15,18
245-12485 CAPSM,CER,.1uF,25V,Z5U,20% 29 C1-7,19,21,24,25
C27-34,36-40,45-47
C49,50
270-00779 FERRITE,BEAD 2 FB13,16
270-06671 FERRITE CHOKE,2.5 TURN 2 FB3,4
270-11545 FERRITESM,CHIP,600 OHM,0805 0 FB1,2,5-12
270-12323 FERRITESM,CHIP,750 OHM,0805 4 FB14,15,17,18
270-14359 COILSM,VAR,1uH,5%,5.6X6.2X6MM 1 L1
300-10509 DIODESM,1N914,SOT23 2 D2,8
300-10563 DIODESM,DUAL,SERIES,GP,SOT23 2 D9,10
300-10564 DIODESM,SCHOTTKY,LOW VF,SOT 2 D3,4
300-11599 DIODESM,GP,1N4002,MELF 2 D5,6
300-13881 DIODESM,VARACTOR,BB132 1 D7
310-10510 TRANSISTORSM,2N3904,SOT23 2 Q1,2
330-09796 ICSM,DIGITAL,74AC00,SOIC 1 U8
330-09889 ICSM,DIGITAL,74ACT04,SOIC 1 U12
330-10523 ICSM,DIGITAL,74HCU04,SOIC 1 U9
330-14355 ICSM,DIGITAL,74HC123A,SOIC 1 U5
330-14357 ICSM,DIGITAL,74FCTT/ABT244SOIC 1 U1
340-09244 ICSM,LINEAR,78LS05,5V REG,SOIC 1 U7

Lexicon 960L Specifications

General

Bit Depth	24-bit
Digital I/O	AES/EBU, S/PDIF
THD+N	<0.01%
Type	Digital Effects System
Sampling Rate	48 kHz
Input Connectors	XLR, AES/EBU
Output Connectors	XLR, AES/EBU
Weight	25 lbs (11.3 kg)
Effects	Reverb, Delay
Inputs	Analog, Digital
Outputs	Analog, Digital
Control	MIDI
Frequency Response	20 Hz - 20 kHz
Presets	100
Power Supply	100-240V, 50/60 Hz
Number of Channels	2 (stereo)
