960L Multi-Channel Digital Effects System Service Manual
8-8
PART NO. DESCRIPTION QTY EFF■INACT REFERENCE
330-13867 ICSM,DIGITAL,74VHC245,SOIC 1 U1
345-14245 ICSM,INTER,CS8403A,XMTR,SOIC 4 U10-13
345-14246 ICSM,INTER,CS8413,RCVR,SOIC 4 U6-9
350-14205 ICSM,FPGA,XCS10-3,14X14,VQFP 1 U2
350-14376 IC,SPROM,960L,AES,V2 1 U3
430-10421 LEDSM,INNER LENS,GRN 1 D1
470-12913 XFORMER,PULSE,AES,1:1,.2X.4SP 8 TX2,4,6,8,10,12
TX14,16
490-02356 CONN,JUMPER,.1X025,2FCG 4 W1-4 pins 2&3
500-05855 CONN,EURO,C,ROW a+b+c,MALE,RA 1 J1
510-02899 CONN,POST,100X025,HDR,3MC 4 W1-4
510-10881 CONN,XLR,3MC,PCRA,PLASTIC 4 J7-10
510-11086 CONN,XLR,3FC,PCRA,LATCH,SMALL 4 J3-6
520-00941 IC SCKT,8 PIN,LO-PRO,TIN 1 U3
620-12428 LUG,#4,INT STAR,XLR GND 4 J7-10
641-11466 SCRW,TAP,#4X3/8,PNH,PH,BZ,TRI 16 XLR (J3-10) TO PANEL
702-13980 PANEL,I/O,AES,960L 1
RVB BD ASSY,960L
202-09794 RESSM,RO,0 OHM,0805 1 R169
202-09871 RESSM,RO,5%,1/10W,1K OHM 22 R41,42,52-56,63,116
R122,125,133,141-143
R161-164,191,195,196
202-09873 RESSM,RO,5%,1/10W,10K OHM 110 R12-39,43-51,57,58
R65-69,71-80,83-87
R89-92,94-102
R105-112,118-121
R123,124,126,140
R145,146,159,160
R166-168,172,173
R177,180-182,184
R186-190,192-194
202-09899 RESSM,RO,5%,1/10W,47 OHM 34 R59-62,113-115
R117,127-132,134-139
R144,147-158,183
202-10557 RESSM,RO,5%,1/10W,4.7K OHM 9 R40,170,171,174-176
R178,179,185
202-10559 RESSM,RO,5%,1/10W,100 OHM 4 R70,82,93,104
202-10569 RESSM,RO,5%,1/10W,10 OHM 4 R64,81,88,103
202-10947 RESSM,RO,5%,1/10W,680K OHM 1 R165
202-10948 RESSM,RO,5%,1/10W,390 OHM 1 R9
202-11073 RESSM,RO,5%,1/4W,270 OHM 8 R1-8
203-10575 RESSM,RO,1%,1/10W,523 OHM 1 R11
203-11077 RESSM,RO,1%,1/10W,237 OHM 1 R10
240-11827 CAPSM,ELEC,10uF,16V,20% 5 C19,22,23,26,27
240-12136 CAPSM,ELEC,33uF,10V,20% 7 C3,5,6,9,10,21,29
245-09876 CAPSM,CER,.01uF,50V,Z5U,20% 4 C34,45,56,67
245-10976 CAPSM,CER,47pF,50V,COG,5% 2 C114,115
245-12460 CAPSM,CER,.056uF,50V,X7R,20% 1 C122
245-12485 CAPSM,CER,.1uF,25V,Z5U,20% 133 C1,2,4,7,8,11-18,20
C24,25,28,30-33
C35-44,46-55,57-66
C68-113,116-121
C123-152
