960L Multi-Channel Digital Effects System Service Manual
8-14
OPT BD ASSY,LARC2
PART NO. DESCRIPTION QTY EFF■INACT REFERENCE
202-09873 RESSM,RO,5%,1/10W,10K OHM 9 R10-18
202-10559 RESSM,RO,5%,1/10W,100 OHM 3 R1-3
202-10586 RESSM,RO,5%,1/4W,100 OHM 1 R9
240-11827 CAPSM,ELEC,10uF,16V,20% 4 C26,28,30,32
245-12485 CAPSM,CER,.1uF,25V,Z5U,20% 17 C1-10,13,14,19,25
C27,29,31
330-13923 ICSM,DIGITAL,74LVC32A,TSSOP 1 U5
330-14314 ICSM,DIGITAL,74LVC125A,SOIC 1 U7
345-13140 ICSM,INTER,RS232 XCVR,+5V,SOIC 2 U1,2
350-14046 ICSM,GAL,22V10,LARC2,OPT,V1.00 1 U4
500-05930 CONN,EURO,C,ROW a+b+c,FEM,RA 1 J4
500-13907 CONN,EURO,C,96P,abc,RECP,VERT 1 J3
510-09773 CONN,MEM CARD,PC,68PIN 1 J2
510-09985 CONN,MEM CARD,68 PIN,EJECTOR 1
510-14172 CONN,DSUB,9MC,PCRA,4-40SCRW 1 J1
640-01706 SCRW,4-40X3/8,PNH,PH,ZN 4 PCMCIA SCKT MTG
643-01733 NUT,4-40,HEX,SMALL,ZN 4 PCMCIA SCKT MTG
SHIP MAT’L/PACKAGING/MISCELLANEOUS
270-14402 FERRITE,RND CABLE,~.8X1.6,SNAP 1 50' CABLE
680-03525 CABLE,50',LARC 1
730-04346 CARD,WARRANTY,LEXICON,8.5X11 1
730-09509 CARD,REGISTRATION,GENERAL 1
730-14316 CERTIFICATE,CE,960L/LARC2 1
730-14317 BOX,17-1/2X12-3/4X9,LARC2 1
730-14326 INSERT,FOAM,LARC2,LEFT 1
730-14327 INSERT,FOAM,LARC2,RIGHT 1
730-14347 CERTIFICATE,CE SA1100 DR,LARC2 1
740-07693 LABEL,LEXICON DIG AUDIO,3"X5" 2
POWER CORDS
680-09149 CORD,POWER,IEC,10A,2M,NA,SVT 1
680-08830 CORD,POWER,IEC,6A,2M,EURO 1
680-10093 CORD,POWER,IEC,5A,2M,UK 1
680-10096 CORD,POWER,IEC,6A,2M,AUSTRALIA1
680-10097 CORD,POWER,IEC,6A,2M,JAPAN 1
680-10094 CORD,POWER,IEC,6A,2M,ITALY 1
680-10095 CORD,POWER,IEC,6A,2M,SWISS 1
680-10098 CORD,POWER,IEC,6A,2M,UNIVERSAL1
SHIP MAT’L/PACKAGING/MISCELLANEOUS
070-14353 MANUAL,OWNER'S,960L 1
070-14354 NOTICE,S/W RELEASE,960L 1
541-00780 BUMPER,FEET,3-M #SJ5023 4
730-04346 CARD,WARRANTY,LEXICON,8.5X11 1
730-09509 CARD,REGISTRATION,GENERAL 1
730-14316 CERTIFICATE,CE,960L/LARC2 1
730-14350 BOX,24X22-3/4X11-1/2,LEXICON 1
730-14352 INSERT,FOAM,4UX17.5 2
730-14516 LICENSE AGREEMENT,END USER 1
740-07693 LABEL,LEXICON DIG AUDIO,3"X5 2
750-14300 CD,960L,V1.05 1
