Lexicon 960L Service Manual

Lexicon
8-13
PART NO. DESCRIPTION QTY EFF■INACT REFERENCE
350-14374 IC,SPROM,LARC2,MAIN,V1.00 1 U41
350-14375 ICSM,FLASH,1M,LARC2,BOOT,V1.00 1 U12
355-13929 ICSM,ADC,TLV1548C,SAR,10b,SSOP 2 U30,31
365-13930 ICSM,uPROC,SA-1100,160MHz,TQFP 1 U8
390-12733 CRYSTAL OSCSM,2MHz,TRI 1 U20
390-13932 CRYSTALSM,32.768kHz,PAR 1 Y1
390-13933 CRYSTALSM,3.6864MHz,PAR,HC49 1 Y2
430-10419 LEDSM,INNER LENS,RED 1 D3
430-10421 LEDSM,INNER LENS,GRN 3 D5,6,14
430-13914 LEDSM,RED,100MCD,3.2X2.8MM 12 D26-31,34-39
440-13906 FUSESM,.75A,RESETTABLE,.18X.13 1 PS1
453-13916 SW,PBM,1P1T,7MMSQ,160GF,PCRA 1 SW1
480-13915 XDUCER,PIEZO-CER,2kHz,50MM LD 1 TO J9,10
500-13908 CONN,EURO,R,96P,abc,PLUG,VERT 1 J6
510-03484 CONN,DC POWER,PC,SMK S-G9314 1 J21
510-13902 CONNSM,FFC,.5MM,18POS,PCRA 1 J3
510-13903 CONNSM,HDR,.059,6P,SHRD,POL 1 J2
510-13909 CONN,MINIDIN,6FC,PCRA,SHLD,GND 1 J19
510-13935 CONNSM,HDR,.059,3P,SHRD,POL 10 J7,8,11-18
510-13936 CONNSM,FFC,.5MM,20POS,PCRA 2 J1,4
510-14172 CONN,DSUB,9MC,PCRA,4-40SCRW 1 J20
520-00941 IC SCKT,8 PIN,LO-PRO,TIN 1 U41
520-13901 IC SCKTSM,PLCC,44 PIN,W/O LOC 1
■07/24/00 U12
530-12360 STRAIN RELIEF,CABLE,MSA XFRMR 1 REAR PANEL
640-01701 SCRW,4-40X1/4,PNH,PH,ZN 5 FADER BRKT MTG (3);
KEYSTONE TO PCB (2)
640-02812 SCRW,4-40X3/8,PNH,PH,BLK 3 RP TO KEYSTONES (2);
STRAIN RELIEF (1)
640-14038 SCRW,M3X4MM,FH,SLOT,ZN,SMHD 16 BRACKET TO FADERS
680-14241 CABLE,059,SCKT/ST&T,3C,3/1.4"L 8 SOLDER GRN/YEL/BLK
WIRES TO FADERS
BEFORE ASSY TO BRKT
701-09640 BRACKET,KEYSTONE,621,4-40X2 2 PCB TO REAR PANEL
701-14214 BRACKET,FADER,LARC2 1
702-14218 PANEL,REAR,LARC2 1
METER BD ASSY,LARC2
202-09871 RESSM,RO,5%,1/10W,1K OHM 8 R1,6,7,11,12,16
R21,22
202-10586 RESSM,RO,5%,1/4W,100 OHM 6 R8-10,13-15
202-11041 RESSM,RO,5%,1/10W,680 OHM 8 R2-5,17-20
241-09798 CAPSM,TANT,10uF,10V,20% 2 C1,3
245-12485 CAPSM,CER,.1uF,25V,Z5U,20% 2 C2,4
310-10422 TRANSISTORSM,2N4403,SOT23 8 Q1-8
330-10535 ICSM,DIGITAL,74AC273,SOIC 2 U1,2
430-13900 LEDSM,GRN,25MCD,3.2X2.8MM 8 D3,6,9,12,15,18
D21,24
430-14312 LEDSM,RED,25MCD,3.2X2.8MM 8 D1,4,7,10,13,16
D19,22
430-14313 LEDSM,YEL,15MCD,3.2X2.8MM 8 D2,5,8,11,14,17
D20,23
510-13936 CONNSM,FFC,.5MM,20POS,PCRA 1 J1
635-14036 SPCR,SWAGE,0-80X1/4,1/8RD,ZN 2 INVERTER
