960L Multi-Channel Digital Effects System Service Manual
8-10
LARC2:
CHASSIS/MECHANICAL:
MAIN HSG ASSY,LARC2
PART NO. DESCRIPTION QTY EFF■INACT REFERENCE
120-14515 ADHESIVE,GLUE,HOT MELT,GP 1.135 CLIP TO FERRITE
HOLDER
270-14401 FERRITE,FLAT CABLE,~.8X1.2,HW 1 INVERTER & DISPLAY
CABLE
453-14226 KEYPAD,MAIN,LARC2 1
453-14228 KEYPAD,SIDE,LARC2 1
530-02489 TIE,CABLE,NYL,.1"X4" 1
550-14035 KNOB,SLIDE,TANG,SATIN/BLK LN 8
550-14230 KNOB,JOYSTICK,LARC2 1
630-12533 WSHR,FL,.120IDX.25ODX.062,RUB 4
640-01716 SCRW,6-32X3/8,PNH,PH,ZN 6 DSPLY HSG TO MN HSG
641-01715 SCRW,TAP,AB,6X3/8,PNH,PH,ZN 8 MAIN BD TO TOP
644-06347 WSHR,FL,.195IDX.437ODX.030THK 2 DSPLY HSG TO MAIN
HSG--ON INSIDE OF
UPPER MAIN HSG.
700-14208 HOUSING,TOP,LARC2 1
700-14211 HOUSING,BOTTOM,LARC2 1
701-14447 CLIP,.78LX.28WX.26H,.100/.156 1
■04/27/00 FERRITE MTG
701-14517 CLIP,.78LX.28WX.29H,.100/.156 1 04/27/00■ FERRITE MTG
720-14223 PAD,FOOT,LARC2 2 HSG, BOTTOM
740-09538 LABEL,S/N,CHASSIS,PRINTED 1 REAR PANEL
740-13573 LABEL,MFR ID,.9X.25,SILVER 1 REAR PANEL
740-14200 LABEL,WARN/APP,PRO,5.75X.98" 1 HSG, BOTTOM
740-14349 LABEL,WINDOWS CE,LARC2 1 MAIN BD (U8)
JOYSTICK ASSY,LARC2
200-13939 POT,STICK CTLR,10K,38MM SQ 1
641-01703 SCRW,TAP,AB,4X1/4,PNH,PH,ZN 4 BRACKET TO POT
680-14239 CABLE,059,SCKT/ST&T,3C,3.5"L 2
701-14215 BRACKET,JOYSTICK,LARC2 1
720-07297 TAPE,COPPER,1/2"W 1
DSPLY HSG ASSY,LARC2
380-13931 DC-AC INV,2W OUT,W/DIMMING 1
640-01716 SCRW,6-32X3/8,PNH,PH,ZN 4 HSG REAR TO FRONT
640-14037 SCRW,0-80X1/4,PNH,PH,ZN 2 INVERTER TO METER BD
641-01715 SCRW,TAP,AB,6X3/8,PNH,PH,ZN 4 LCDBRKT TO DSPLY HSG
680-14235 CABLE,FFC,20CX.5MM,7.5" 1 TO METER BD (J1)
680-14238 CABLE,HSG/HSG,5C/6C,8.5" 1 TO INVERTER
700-14212 HOUSING,DSPLY,FRONT,LARC2 1
700-14213 HOUSING,DSPLY,REAR,LARC2 1
701-14447 CLIP,.78LX.28WX.26H,.100/.156 2
703-14207 LENS,LCD,LARC2 1
703-14221 OVLY,METER BRIDGE,LARC2 1
720-14520 SPCR,PVC,~6.8X3.0X.02",BLK,ADH 1 07/26/00
■
