Lexicon 960L Service Manual

960L Multi-Channel Digital Effects System Service Manual
8-4
PART NO. DESCRIPTION QTY EFF■INACT REFERENCE
340-11573 ICSM,LIN,NJM4580,DUALOPAMP,SOP 1 U6
340-12111 ICSM,LIN,MC12148,VCO,LPWR,SOIC 1 U10
345-12038 ICSM,INTER,75ALS180,DR/RC,SOIC 3 U13-15
350-14373 ICSM,CPLD,960L,I/O CLK,V1.10 1 U2
375-12110 ICSM,OPTO-ISOL,HCPL0601,SOIC 1 U11
390-12978 CRYSTAL OSC,22.5792MHz,10PPM 1 U4
390-12979 CRYSTAL OSC,24.576MHz,10PPM 1 U3
430-10419 LEDSM,INNER LENS,RED 1 D1
440-13906 FUSESM,.75A,RESETTABLE,.18X.13 2 PS1,2
500-05855 CONN,EURO,C,ROW a+b+c,MALE,RA 1 J1
510-03550 CONN,DSUB,9FC,PCRA,4-40THD INS 2 J9,10
510-08634 CONN,BNC,1FC,MB,PCRA,GLD 1 J8
510-09790 CONN,DIN,5FC@180DEG,PCRA 3 J3-5
510-12326 CONN,BNC,PCRA,SELF-TERM,75 2 J6,7
527-12974 CONN,DSUB,JSCKT,4-40,.187X.25 4 DSUB(J9,10) TO PANEL
620-12915 LUG,SOLDER,.52IDX.7OD/FL.25TAB 2 J6,7
641-09699 SCRW,TAP,AB,#2X5/16,PNH,PH,ZN 3 DIN(J3-5) TO PANEL
643-04942 NUT,1/2-28,HEX,BRASS/NI 3 BNC(J6-8) TO PANEL
644-04943 WSHR,INT STAR,1/2" 3 BNC(J6-8) TO PANEL
702-13973 PANEL,I/O,CLK,960L 1
AIN BD ASSY,960L
202-09794 RESSM,RO,0 OHM,0805 10 R1,10,17-24
202-09873 RESSM,RO,5%,1/10W,10K OHM 5 R7-9,11,16
202-09899 RESSM,RO,5%,1/10W,47 OHM 9 R2-6,12-15
202-10426 RESSM,RO,5%,1/10W,15K OHM 8 R81,84,85,88,89,92
R93,96
203-10583 RESSM,RO,1%,1/10W,10.0K OHM 16 R97-112
203-12363 RESSM,RO,1%,1/10W,90.9 OHM 16 R33-48
203-12477 RESSM,RO,1%,1/10W,13.3K OHM 8 R82,83,86,87,90,91
R94,95
203-13219 RESSM,THIN,1%,1/10W,422 OHM 8 R25-32
203-13917 RESSM,THIN,1%,1/10W,40.2K OHM 16 R113-128
203-13918 RESSM,THIN,.1%,1/10W,4.02K OHM 16 R49,52,53,56,57,60
R61,64,65,68,69,72
R73,76,77,80
203-14296 RESSM,THIN,1%,1/10W,6.49K OHM 16 02/17/00
■ R161-176
203-14437 RESSM,THIN,.1%,1/10W,13.3K OHM 32 R129-160
203-14438 RESSM,THIN,.1%,1/10W,2.74K OHM 16 R50,51,54,55,58,59
R62,63,66,67,70,71
R74,75,78,79
240-09786 CAP,ELEC,100uF,25V,RAD,LOW ESR 2 C7,8
240-11111 CAPSM,ELEC,47uF,6V,NONPOL,20% 16 C83,85,87,89,91,93
C95,97,99,101,103
C105,107,109,111,113
240-11827 CAPSM,ELEC,10uF,16V,20% 24 C10,13,14,17,18,21
C22,25,50-58,61,62
C65,66,69,70,73
244-10423 CAP,MYL,.22uF,50V,RAD,5%,BOX 4 C2,3,5,6
245-10562 CAPSM,CER,150pF,50V,COG,10% 18 C1,4,82,84,86,88,90
C92,94,96,98,100,102
C104,106,108,110,112
245-11596 CAPSM,CER,6800pF,50V,COG,5% 8 C35,36,39,40,43,44
C47,48

Lexicon 960L Specifications

General

Bit Depth	24-bit
Digital I/O	AES/EBU, S/PDIF
THD+N	<0.01%
Type	Digital Effects System
Sampling Rate	48 kHz
Input Connectors	XLR, AES/EBU
Output Connectors	XLR, AES/EBU
Weight	25 lbs (11.3 kg)
Effects	Reverb, Delay
Inputs	Analog, Digital
Outputs	Analog, Digital
Control	MIDI
Frequency Response	20 Hz - 20 kHz
Presets	100
Power Supply	100-240V, 50/60 Hz
Number of Channels	2 (stereo)
