Lexmark C912 Setup Guide

Installing height adjustment spacers If the pins on the high capacity feeder do
not align with the holes in the docking
frame, adjust the height of the feeder.
You can either remove the factory
installed spacer or add two spacers
between each caster and the bottom of
the high capacity feeder.
Use the following steps to add or remove
spacers.
1 Determine the height difference
between high capacity feeder
alignment pins and the docking
frame.
2 Place the high capacity feeder on
the floor or adequate work surface.
3 Remove the four screws securing
one of the casters to the high
capacity feeder.
4 Add or remove spacers.
To add spacers:
a Insert the four screws through
the caster.
b Place the spacers on the
screws.
c Align and insert the screws into
the screw holes on the high
capacity feeder.
Set up the printer and paper handling options
15
