Reinstalling the system board
access cover
Screw slot
After you finish installing cards on the
printer system board, reinstall the system
board access cover.
1 Align the holes on the access
cover with the screws on the
printer.
2 Place the cover against the printer
and slide it down.
3 Tighten the eight screws.
Install memory and option cards
37
