3 Use the illustration to locate the
connector for the card you want to
install.
Optional hard disk
Optional ImageQuick firmware card
Option card connector
Memory and flash memory card connectors
Parallel connector
Ethernet connector
USB connector
Option card cover
4 Use the following table to locate
the instructions you need.
To install a... Go to page...
Memory card 32
Firmware card 33
Hard disk 34
Option card 35
Install memory and option cards
31
