Printer roller locations

Standard path rollers

1 Photoconductor drum

2 First input roller

3 MPF pick roller

4 Second input roller

5 Pick roller

6 Separator roller

7 Transfer roller

8 Fuser roller

9 Fuser exit roller

10 Paper exit roller
