Assembly 11: Imaging
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1329 1 1 ADF assembly
“ADF assembly removal” on
page 310
2 41X1335 1 1 ADF tray
“ADF tray removal” on page 307
3 41X2221 1 1 ADF cable cover --
441X1321 1 1ADF right hinge
“ADF right hinge removal” on
page 312
5 41X1324 1 1 ADF cushion --
640X9129 1 1ADF left hinge
“ADF left hinge removal” on
page 311
7 41X1318 1 1 ADF access door
“ADF access door removal” on
page 313
8 41X1326 1 1 ADF roller
“ADF roller removal” on page 306
9 41X1325 1 1 Standard ADF separator
roller
Note: For printers that
experience frequent
multi‑feed operations, use
the High torque ADF
separator roller (41X2855)
when replacing the ADF
separator roller.
“ADF separator roller removal” on
page 306
9 41X2855 1 1 High torque ADF separator
roller
“ADF separator roller removal” on
page 306
10 41X1322 1 1 ADF restraint pad
“ADF restraint pad removal ” on
page 305
11 41X1332 1 1 Flatbed scanner
“Flatbed scanner assembly
removal” on page 314
12 41X1315 1 1 ADF cable --
13 41X1316 1 1 ADF flat cable
“ADF flat cable removal” on
page 316
7018
