Replacing the fuser
The fuser is one of the items in the maintenance kit. Replace it when 80 Scheduled Maintenance
appears.
Removing the old fuser
1 Turn the printer off.
2 If the envelope feeder is attached to the printer, remove it. See Removing the optional
envelope feeder.
3 If a duplex unit is attached to the printer, open the duplex unit door (Door E).
a Push up on the latch to release the door.
b Gently lower the door to the open position.
4 Pull up on the handle to open the printer side door (Door A). Gently lower the door to the open
position.
