Lexmark XC9235 - Page 301

22 Connect the 2 x 500‑ or 2500‑sheet tray connector to the printer.
23 Open trays 2 and 3, and then secure the 2 x 500‑ or 2500‑sheet tray to the printer with the locking clips
and metal bracket.
• Front
Upgrading and migrating 301
