3-3
9. Remove a cooktop plate assembly (See the page
3-6) and remove 4 screws from side panel.
10. Remove 4 screws from the controller assembly
(back guard R/L)
11. Remove 6 screws from the controller assembly.
12. For serving the KEY Membrane, the controller sub
assembly should be separated in whole. Both
Control-panel and KEY Membrane are 1 service
part.
COMPONENT ACCESS
To Next Page
