7. Chapter 7 - SPECIFICATION
SERIES 7400 UPS INDIVIDUAL MODULE SPECIFICATION
Note: These specifications give the parameters for the standard 6 Pulse module and the 6 Pulse module with the 12 Pulse option fitted.
MECHANICAL UNITS Model kVA Rating
CHARACTERISTICS 80 120 200 300 400
6 Pulse 12 Pulse 6 Pulse 12 Pulse 6 Pulse 12 Pulse 6 Pulse 12 Pulse 6 Pulse 12 Pulse
Height mm 1 800 1900
Width mm 900 1300 1 250 1650 1 400 1 900 2 460
Depth mm 800
Weight kg 750 950 1000 1200 1 350 1 750 2140 2650 2340 2850
Colour (two tone) — RAL 7035 (light grey)
RAL 7016 (dark grey)
Protection grade — With enclosure shut — IP20
With front door open — IP20
Ventilation — by internal intake fans
Airflow m
3
/h 1800 2150 2600 2950 4400 4750 6160 6160 8820 8820
Cable entry — Bottom or either side Top or Bottom
ENVIRONMENTAL
Operating temperature o
C
0 — 40
Maximum temperature for 8 hr
day
—
40
o
C derate by 1,5% per
o
C between 40
°
C — 50
°
C
Mean temperature for 24 hr day o
C
35 max
Relative humidity —
≤ 90% at 20°C
Altitude
≤ 1000m asl (derate by 1% per 100m between 1000 and 2000m)
Storage temperature o
C
-25 to +70
