Liebert 7400 Series User Manual

7400 Series UPS User Manual Chapter 1 - General Description
Single Module and One plus One Systems Design Concept
6310018a.02.doc
1-7
Issue 2
(02/98)
200 kVA
120 kVA
300-400 kVA
80 kVA
I4 I3 I2 I1
I4 I1
I3
I2
I1 = Input Isolator
I2 = Static Bypass Isolator
I3 = Maintenance Bypass Isolator (with padlock)
I4 = Output Isolator
I4 I3 I2 I1
I4 I3 I2 I1
Figure 1-1 . Power isolator identification
