32 User Manual 10H52192UM60 - Rev. 1 - 09/2011

Liebert NX Installing Parallel Systems

UPS 1

Bypass module

LBS cable

UPS 3 UPS 4

Bypass module Bypass module Bypass module

UPS 2

LBS cable

Figure 3-7 Connection of Typical Dual Bus System of Two Parallel Systems

UPS 1

Bypass module

LBS cable

Bypass module

UPS 2

Figure 3-8 Connection of Typical Dual Bus System of Two Single UPS Modules Without Redundancy LBS Cable

UPS 1

Bypass module

UPS 2

Figure 3-9 Connection of Typical Dual Bus System of Two Single UPS Modules with Redundancy LBS Cable
