PHASE 4
CARD INITIALISATION













O
F
F
230V
230V
OFF
O
N
230V
230V
ON


































a)
Switch off power supply.
b)
S
imultaneously press and hold down
and
and switch
on the power supply to the system to light the third LED.
c
)
R
elease keys
and
,
the two red LEDs will now ash.
PHASE
4.1






































In the case of a
SINGLE
operator only press
: the red LED
(DX)
lights.
B
eing a single leaf system, staggering will not be indicated
for the manoeuvres below.
PHASE 5
LEAF 2 LEAF 1 CLOSURE STOP PLATE IDENTIFICATION


















EL0016
EL0016
EL006a
1
2
2











EL006b
1
1
2
2
a)
G
ive the step command
(A)
, holding it down until leaf
(2)
s
lowly reaches and pushes for a few seconds against the
c
losure stop plate.
Press
to identify the stop plate: the
red led
(DX)
will light.
When the leaf
(2)
has identifi ed the
closure stop plate the
red LED
(DX)
only remains lit.
b)
G
ive the step command
(A)
, holding it down until leaf
(1)
s
lowly reaches and pushes for a few seconds against the
c
losure stop plate.
P
ress
to identify the stop plate: the
r
ed led
red led r
(SX)
will light.
When the leaf
(1)
has identifi ed the
c
losure stop plate the
red LEDs
(SX)
and
(DX)
remain lit.
