Lightware MX-FR9 - Commands - Quick Summary

 MX-FR Series Modular Matrix Frames – User's Manual 146


Switching and Control Commands
Test Input and Preview Output
Selecting the 80th Input Port (MX-FR80R)
ȩ {TI=<value>}
Switching an Input to an Output
ȩ {<in>@<out>}
Switching an Input to All Outputs
ȩ {<in>@O}
Diagonal Switching
ȩ {<in>@D}
Batch Switch Outputs
Displaying the Current Connection States of the Outputs
ȩ {VC}

ȩ {VM}

ȩ {#<out>}

ȩ {+<out>}
Disconnecting an Output
ȩ {0@<out>}
Disconnecting All Outputs
ȩ {0@O}

ȩ {#><out>}

ȩ {+<<out>}
Saving a Preset
ȩ {$<id>}
Loading a Preset
ȩ {%<id>}
Preset Preview
ȩ {VP#<id>=?}
Renaming a Preset
ȩ {PNAME#<id>= <preset_name>}
Renaming an Input
ȩ {INAME#<in>=<input_name>}
Renaming an Output
ȩ {ONAME#<out>=<output_name>}

ȩ {PNAME#<id>=?}

ȩ {INAME#<in>=?}

ȩ {ONAME#<out>=?}
Reloading the Default Preset Names
ȩ {PNAME#<id>=!}
Reloading the Default Input Names
ȩ {INAME#<id>=!}
Reloading the Default Output Names
ȩ {ONAME#<id>=!}
Communication Setup Commands

ȩ {IP_CONFIG=?}
Reloading the Default IP Settings
ȩ {IP_CONFIG=!}
Setting a Dynamic IP Address (DHCP)
ȩ {IP_CONFIG=D}

ȩ {RS232BAUD=?}




