11. Appendix MX-FR Series Modular Matrix Frames – User's Manual 176
Resolution
Pixel Clock Rate
Cable Lengths
CA
T5e
AWG24
CA
T7
AWG26**
CAT7
AWG23
1024x768@60Hz 65
1280x720p@60Hz 73.8
148.5
1920x1200@60Hz 152.9
1600x1200@60Hz 162
223.6
3840x2160@30Hz UHD 297
4096x2160@30Hz 4K 297
To specify the accurate extension distances, please also check the documentation of the connected
HDBaseT-compatible device.
Resolution CAT5e UTP CAT5e FTP
CAT6
UTP
CAT6
FTP
CAT6 SFTP CAT7 SFTP
640x480@60 60 m 60 m 65 m 70 m 70 m 80 m
800x600@60 60 m 60 m 65 m 65 m 65 m 75 m
1024x768@60 55 m 55 m 60 m 60 m 60 m 75 m
1280x720p60 55 m 55 m 60 m 60 m 60 m 70 m
1280x1024@60 50 m 50 m 55 m 60 m 60 m 65 m
1400x1050@60 45 m 45 m 45 m 55 m 55 m 60 m
1600x1200@60 30 m 35 m 35 m 45 m 45 m 50 m
1920x1080p60 30 m 35 m 35 m 45 m 45 m 50 m
1920x1200p60 30 m 35 m 35 m 45 m 45 m 50 m
Firmware Release Notes
3.0.0
Released: 2010-07-14
New feature
▪ MX-FR16 support
▪ MX-FR80 support
▪ MX-DVID-IB, MX-DVID-OB support
▪ MX-DVI-TP-IB, MX-DVI-TP-OB support
▪ MX-DVI-TP-IB+, MX-DVI-TP-OB+ support
▪ MX-OPT-DVI-OB, MX-OPT-DVI-OB-RCLK support (including SX4A and SX4B optical modules)
▪
▪ Implements a test input and a preview output port on the CPU card
▪ SMPTE alarm function
▪ Advanced EDID management, HDMI support is automatically stripped if needed
▪ LCD menu, control board
▪ Date and time functions
▪
Lightware protocol).
▪ Monitoring the voltages, fan speeds and power supplies
▪ PROTOCOL#2 support
▪ Standby mode
3.0.1
Released: 2010-09-16
New feature
▪ MX-FR32R support
▪ Extended reliability, watchdog + task autorestart
▪ MX-HDMI-IB, MX-HDMI-OB support (including audio support)
▪ MX-DVI-HDCP-IB, MX-DVI-HDCP-OB support
▪ MX-OPT-DVI-IB support
▪ MX-DVIDL-IB, MX-DVIDL-OB support
▪ HDCP is supported by crosspoint level (HDCP protected signal is routed only to compatible output
boards, so mixed cards are supported).
