11. Appendix MX-FR Series Modular Matrix Frames – User's Manual 173
Ethernet Port
Connector type .............................................................................
Ethernet data rate ..........................................................................
Power over Ethernet (PoE) ..........................................................................................................Not supported
Ethernet protocol .....................................................................................................
Alarm Output
Connector type ...................................................................................................... SMPTE 269M standard BNC
device and the softwares:
Purpose/function
Affected
software
Protocol Port nr.
Device Discovery LDC UDP 224.0.0.251:5353
Remote IP LDC UDP 230.76.87.82:37421
- TCP 10001
HTTP port - TCP 80
Factory Default Settings
Network Settings
IP address 192.168.254.254
Subnet mask 255.255.0.0
Static gateway 0.0.0.0
DHCP Disabled
10001
HTTP Port number 80
Control protocol
Video Port Settings
Crosspoint state I1 input port on all output ports
Unmuted, Unlocked
Emulated EDID (input ports) F49 – Universal HDMI EDID
EDID memory Empty (User and Dynamic EDIDs)
Crosspoint presets All outputs to I1
Preset names Preset1, Preset2,...
Port names Input1, Input2...; Output1, Output2...
RS-232 Settings
Baud rate 57600
Databits 8
Parity No
Stopbits 1
Control protocol
