11. Appendix MX-FR Series Modular Matrix Frames – User's Manual 170

Audio formats .............................................................................................................................8 channel PCM
...........................................................................................................Dolby TrueHD, DTS-HD Master Audio 7.1
Input cable equalization .......................................................................................................... 

Connector type ................................................................................................................................ 29-pole DVI-I
AV standard .............................................................................................................................................. DVI 1.0
Color space ................................................................................................................................................... RGB
Video delay .............................................................................................................................................. 0 frame
 ............................................................up to 2560x1600@60Hz (4:4:4)
..................................................................................................................................1920x1200@120Hz, 24 bit
3D support ...................................................................................................................................................... 
Audio formats .............................................................................................................................8 channel PCM
Input cable equalization .......................................................................................................... 

Connector type ................................................................................................................................ 29-pole DVI-I
AV standard .............................................................................................................................................. DVI 1.0
Color depth ................................................................................................................. 
Color space ......................................................................................................... 
Max. video resolutions ...........................................................................................1600x1200@60 Hz, 24 bits
3GSDI Input
Connector type .............................................................................................................................................. BNC
AV standard ...............................................................................................................................................3G-SDI
Color depth .................................................................................................. 
Color space .................................................................................................................................................20 bit
Supported video formats ..............................................................................................SD-SDI, HD-SDI, 3G-SDI
3D support ....................................................................................................................................................... No
EDID emulation ............................................................................................................................................... No
Audio capability ..........................................................................................................................8 channel PCM
TPS Input
Connector type ...........................................................................................................................
Power over Ethernet (PoE) .................................................................................................yes * (IEEE 802.3af)
Compliance ....................................................................................................................................... HDBaseT
TM
HDCP compliance ................................................................................................................................ HDCP 1.4
Transferred signals .............................................................................Video, Audio, RS-232, Infrared, Ethernet
Color space .......................................................................................................................................
Video delay .............................................................................................................................................. 0 frame
 ....... up to 4096x2048@30Hz (4:4:4) or 4096x2048@60Hz (4:2:0)
......................................................................... up to 3840x2160@30Hz (4:4:4) or 3840x2160@60Hz (4:2:0)
................................................................................................... 
Audio formats .............................................................................................................................8 channel PCM
...........................................................................................................Dolby TrueHD, DTS-HD Master Audio 7.1
* PoE function is available for the MX-TPS-IB-P series input boards only.
Video Outputs - I/O Boards
INFO:  

Connector type ............................................................................................... 19-pole HDMI Type A receptacle
AV standard ............................................................................................................................. DVI 1.0, HDMI 1.4
HDCP compliance ................................................................................................................................ HDCP 1.4
Color space .......................................................................................................................................
Video delay .............................................................................................................................................. 0 frame
 ....... up to 4096x2048@30Hz (4:4:4) or 4096x2048@60Hz (4:2:0)
......................................................................... up to 3840x2160@30Hz (4:4:4) or 3840x2160@60Hz (4:2:0)
................................................................................................... 
Audio formats .............................................................................................................................8 channel PCM
...........................................................................................................Dolby TrueHD, DTS-HD Master Audio 7.1
Input cable equalization .......................................................................................................... 
** All standard VESA, CEA and other custom resolutions up to 300MHz (HDMI1.4) are supported.




