11. Appendix MX-FR Series Modular Matrix Frames – User's Manual 179
▪
and 0-7800 in 0.01dB steps.
▪ Added 3D support for MX-HDMI-IB, MX-DVI-HDCP-IB, MX-HDMI-TP-IB, MX-CPU2 test input and preview
output, MX-HDMI-OB, MX-DVI-HDCP-OB, MX-HDMI-TP-OB boards. The detected format is reported back
in :HDMI command using the "reserved for future use" byte after colorspace. 1920x1080p, 1280x720p
and 640x480p formats are supported in frame-packing, top-bottom, side-by-side mode.
▪ Protocol#2 switching commands didn't handle DL outputs at all.
▪ Commands were sometimes not recognized, there was no response (about every 10.000th switch).
▪ Preset load and Diagonal switch commands didn't consider DualLink ports.
▪ Protocol#2 commands were interpreted while using Protocol#1- now only Protocol#1 commands are
accepted.
▪ Syntax error in a*b% Protocol#2 command reply
▪
▪ More than 32 preset could be saved in FR80R frame from front panel control board. Now it is only 32.
▪ CB issue: muted output button didn't blink when the source input button was pressed twice.
▪ DVI-I boards sometimes reported HDMI signals when DVI signal was present.
▪
darker.) Now it is treated as full range - This involves only digital DVI signals.
▪ Preview output and HDCP output boards sometimes didn't detect the sent signal - especially with some
▪
TASK RESET error message.
▪ I2C speed has been reduced to 100 kHz during retrying the communication when NACK received from
a SiI9134 or a SiI9135.
▪ MXD_HDMI_TP_IB support.
▪ The default LCD menu page was the main menu structure on the 4-line LCD. Now it is the the Router
Status page - similarly to the old 2-line display.
▪
▪ I2C speed was reduced to achive more robostusness.
▪ SignalPresent and EDID menu problem in case of autotake mode has been solved.
3.1.4
Released: 2011-07-25
New feature
▪
FR80R frame.
▪ Complete status is saved to the SD card after the booting process if an error occurs.
▪ Timezones are supported (by adding UTC+nnnn to the end of the time, e.g. 22.07.2011. 15:33:52
UTC+0100)
▪ Changing time is logged to the SD card.
▪ Batch command processing for switch commands works on both Protocol#1 and Protocol#2.
▪ There is no E_S_C when a user EDID is uploaded.
▪ Front panel IP reset (ctr lock + output lock) works now
▪ MX-DVI-OPT-IB SCH_2.2 laser powers weren't applied after boot.
▪
▪ USB enumeration failed at boot cycle
▪ 'No card found' error is only a warning and not a fatal error.
3.1.6
Released: 2011-09-22
New feature
▪ Batch commanding applies wait for next command for faster execution.
▪ If a power supply looses AC then an error is generated. If it never had AC then no error is generated
(only a warning).
▪
command.
▪ RS232 baudrate can be adjusted from Lightware protocol by {RS232BAUD=.....} command.
▪
control lock, communication protocols).
▪
▪
▪
▪ EDID switch on all inputs caused COMMTASK reset.
▪ HDMI LED remained ON when the source was disconnected. The problem occurred when the incoming
signal was content protected and the input was switched to multiple output.
▪ MX-HDMI-TP-OB: there was no PSC event and the response for {PS} was all '0'
▪ 4line LCD didn't respond to menu button press in some cases.
▪ 4line LCD EDID switch menu showed '0' for the destination after startup and there was no 'ALL' option.
▪
'VOLTAGE ALERT'.
