2.2. MX-DVI-FR16
The MX-DVI-FR16 modular frame allows building custom matrices with up to 16
inputs and 16 outputs. The card in the uppermost slot must be a CPU card that is
responsible for controlling the matrix. The two input and two output slots accept
any kind of input and output card which are described in section 2.5 and section
2.6.
The front panel has exactly the same controls as the MX8x8 series but with 16
input and 16 output selector buttons.
2.2.1. Rear view of MX-DVI-FR16
Power switch CPU Card Output cards (1..2)
AC Power AC Fuse Input cards (1..2)
connector (F 3.15A only)
2.3. MX-DVI-FR32R
The MX-DVI-FR32 modular frame allows building custom matrices with up to 32
inputs and 32 outputs. The card in the uppermost slot must be a CPU card that is
responsible for controlling the matrix. The two input and two output slots accept
any kind of input and output card which are described in section 2.5 and section
2.6.
The front panel has exactly the same controls as the MX8x8 series but with 32
input and 32 output selector buttons.
This frame can be ordered with redundant power supply.
