4.1.18. Load DHCP IP settings (only IP address!)
Description: After issuing this
command (either over serial or IP) the
router will reload the factory default IP
setup.
Parameters after successful command execution:
4.2. Router Status Commands
4.2.1. View product type
Description: The router responds its name.
Example:
4.2.2. View serial number
Description: The router responds its 8-digit
serial number.
Example: The serial number of the connected
router is: 06050100.
Info: Only the last 4 numbers are written onto the back of the router
4.2.3. View Firmware version of the CPU
Description: View the CPU firmware revision.
To view another controller’s firmware revision
see → ’Query cards' firmware’ {FC}.
Example: The connected router’s CPU has a
firmware version of 1.10.
→
{IP_CONFIG=
D
}
← (Changing IP configuration…)CrLf
…4 second delay…
… Beep Beep sound from the router…
← (DONE!)CrLf or (FAILED!)CrLf
Parameter
Value
IP address Acquired with DHCP
port number unchanged
Subnet mask unchanged
Gateway unchanged
→ {I}
← (PRODUCT_TYPE)CrLf
MX32x32
→ {I }
← (MX32X32DVI FRAME)CrLf
MX16x16
→ {I}
← (MX16X16DVI FRAME)CrLf
MX8x8
→ {I}
← (MX8X8DVI FRAME)CrLf
→ {S}
← SN:<SERIAL_NUMBER>)CrLf
→
{S}
←
(SN:06050100)CrLf
→ {F}
← (FIRMWARE_VERSION)CrLf
→
{F}
←
(FW:1.1.0)CrLf
