Page 24 / 109
Fiber B Fiber A
LC connector
Fiber B Fiber A
SC connector
2.8.2. BR-N Optional Neutrik breakout box
Since Neutrik connectors have two independent fibers in one cable, Lightware
offers the BR-NT Optional Neutrik breakout box to separate the individual signals
from each other.
BR-NT Neutrik breakout box
The breakout box is a passive component and it adds 1 dB attenuation to each
fiber.
