Logical EDID locations:
Factory presets User presets Outputs Inputs
MX32x32
1..50 51..100 101..132 133..164
MX16x16
1..50 51..100 101..116 133..148
MX8x8
1..50 51..100 101..108 133..140
4.3.5. Save EDID from output to memory location (Learn EDID)
Description: Learn EDID from the specified
output <out> to the specified location <loc>.
Example:
4.3.6. View EDID validity table
Description: Shows EDID validity table, which
contains information about the EDID states.
If a changed EDID is queried by the wh command (see the next section), its value
returns to ‘1’.
Example
Legend:
MX32x32
→ {WV}
←
(EV 1111111111111111111111111111111111111111
11111111110003301100000000000000000000000000
00000000000000001331111111111111111111111111
111111111111111133111111111111111111)CrLf
MX16x16
→ {WV}
←
(EV 1111111111111111111111111111111111111111
11111111110003301100000000000000000000000000
00000000000000001331111111111111000000000000
000011111111111133110000000000000000)CrLf
MX8x8
→ {WV}
←
(EV 1111111111111111111111111111111111111111
11111111110003301100000000000000000000000000
00000000000000001331111100000000000000000000
000011111111000000000000000000000000)CrLf
Value
Description
’0’
invalid EDID
’1’
valid EDID
’3’
changed EDID
4.3.7. View EDID header
Description: EDID_HEADER consist of 3
→ {<out>><loc>}
← (E_SW_OK)CrLf
← (E_S_C) CrLf
→ {24>51}
← (E_SW_OK)CrLf
← (E_S_C) CrLf
→ {wv}
← (EV●VALIDITY_TABLE)CrLf
→ {wh<loc>}
← (EH#<loc>●EDID_HEADER)CrLf
