Lightware UMX-TP-TX100R User Manual

UMX-TP-TX100R
Programmer’s Reference Manual
Section 4. Programmers reference Page 15 / 43
4.3. Status and identification commands
4.3.1. View product type
Description: Identification of the device. Type ‘i’ or ‘I’ then the router responds its name.
Format
Example
Command
{I}
→
{i}
Response
(<PRODUCT_TYPE>)CrLf
←
(I:UMX-TP-TX100R)CrLf
Legend: <PRODUCT_TYPE> shows the router model.
Explanation: The connected device is an UMX-TP-TX100R.
4.3.2. View serial number
Description: The extender responds its 8-digit serial number.
Format
Example
Command
{S}
→
{s}
Response
(<SERIAL_NUMBER>)CrLf
←
(SN:10170142)CrLf
Legend: < SERIAL_NUMBER > shows the serial number of the extender.
Explanation: The connected device’s serial number is 10170142.
Info: Only the last 4 numbers are written onto the back of the router
4.3.3. View Firmware version of the CPU
Description: View the CPU firmware revision.
Format
Example
Command
{F}
→
{f}
Response
(FW:<FW_VER><S>)CrLf
←
(FW:1.0.9r)CrLf
Legend: <FW_VERSION> is the firmware version. It is followed by <s> string which may
indicate special versions. <s>=r indicates standard version.
Explanation: The connected device’s firmware version is 1.0.9r.
4.3.4. View installed controllers’ firmware
Description: Shows the firmware revisions of the installed controllers.
Format
Example
Command
{FC}
→
{fc}
Response
(CF●END)CrLf
←
(CF END)CrLf
Explanation: There is no installed controller. This command is reserved for compatibility
reasons.
4.3.5. View device’s temperature
Description: Queries temperature status.
Format
Example
Command
{ST}
→
{st}
Response
(ST●<DESC>)CrLf
←
(ST CPU N/A N/A N/A N/A N/A 36.2C)CrLf
Legend: <DESC> N/A N/A N/A N/A N/A – reserved for compatibility reasons
INNER TEMPERATURE
Explanation: Internal temperature is shown.
