Section 4. Programmers reference Page 37 / 43
4.8.20. Delete preset from all input ports
Description: This command deletes the desired from all analog input ports.
Format
Example
Command
{:AF#<in>@SI=DELALL;<PID>}
→
{:af#2@si=delall;1}
Response
(AF DELETED)CrLf
←
(AF DELETED)CrLf
Legend: <PID> Preset ID number
Explanation: This command is reserved for compatibility reasons.
4.9. Output properties
The following commands are setting up the properties of the output ports. If only one or a
few parameters have to be modified, the protocol enables to mask the other parameters,
so they can stay untouched. To mask a parameter use “x” or “X” as its value.
Example: {:HDMI#1@SO=H;x;x;x;1;} Set output port no. 2 to HDMI 24 bit.
4.9.1. Set output video properties
Description: This command is for configuring output port settings.
Format
Example
Command
{:HDMI#<out>@<S/A>O=
<MODE>;
<CSPAC>;
<CRANG>;
<SUBS>;
<HDCP>;}
→
{:HDMI#1@SO=H;x;x;x;1;}
Response
(HDMI#<out>@<S/A>O=
G<CON><MODE><SIG>
<HDCP><HPD>;
O<MODE><CSPAC>
<CRANG>;<SUBS> <HDCP>)
M<HSUP><AUTH><REP>
<YUV4><YUV2>
<AUD><PCM><DC>CrLf
←
(HDMI#2@SO=G0H100;OHAAA1;)CrLf
Legend for command:
<S/A>: Affected ports:
S = single-selected output
A = all outputs
<MODE>: Output signal mode:
A = Automatic (this setting gives a response as D/H/1/2),
D = DVI,
H = HDMI 24bit,
1 = HDMI 30bit deepcolor,
2 = HDMI 36bit deepcolor.
<CSPAC>: Reserved for legacy reasons. Set ‘X’ here.
<CRANG>: Reserved for legacy reasons. Set ‘X’ here.
<SUBS>: Reserved for legacy reasons. Set ‘X’ here.
<HDCP>: HDCP encryption:
A = automatic,
1 = always use.
Legend for response:
G block: General status information
<CON>: Connection sense:
0 = There is no attached sink device,
1 = Sink device attached (termination is present)
