Actuator with absolute positioning - Analogue feedback
I/O specifications
Yellow Analogue feedback
0-10 V (Option B)
0�5-4�5 V (Option C)
Tolerances: +/- 0�2 V
Max� current output: 1 mA
Ripple max�: 200 mV
Transaction delay: 100 ms
Linear feedback: 0�5 %
The actuator should be made to
activate its limit switches on a
regular basis to ensure more
precise positioning�
White Not to be connected
Brown Not to be connected
Violet Not to be connected
