Electrical installation
• To ensure maximum self-locking ability, please be sure that the motor is shorted when stopped�
Actuators with integrated controller provide this feature, as long as the actuator is powered�
• When using soft stop on a DC-motor, a short peak of higher voltage will be sent back towards the
power supply� It is important when selecting the power supply that it does not turn off the output,
when this backwards load dump occurs�
The power supply for actuators without integrated controller must be monitored externally and cut off
in case of current overload�
Recommended fuse for actuators without integrated controller
Type Spindle Pitch
(mm)
Thrust max. Push/
Pull
(N)
Typical Amp. at
full load
(A)
24 V - 12 V
Recommended fuse
24 V - 12 V
12xx00-1xxx12xx 2 750 - 4�6 - 9�2
12xx00-1xxx24xx 2 750 2�2 - 4�4 -
12xx00-2xxx12xx 4 300 - 2�5 - 5�0
12xx00-2xxx24xx 4 300 1�5 - 3�0 -
12xx00-3xxx12xx 6 200 - 2�2 - 4�4
12xx00-3xxx24xx 6 200 1�0 - 2�0 -
