Specifications
Motor: Permanent magnet motor 12 or 24 V
Housing: High strength-plastic housing
Spindle part: Acme spindle: Trapezoidal spindle with high efficiency
Temperature range: - 20
o
C to +60
o
C
- 4
o
F to +140
o
F
Full performance +5
o
C to +40
o
C
End play: 2 mm maximum
Weather protection: Rated IPX1, or if chosen as option IP66
Endstop switches: Built-in endstop switches
Piston rod and High-strength plastic as standard
back fixture:
Usage:
• Duty cycle at 750 N and 2 mm pitch is max� 10 %
Duty cycle at 300 N and 4 mm pitch is max� 40 %
Duty cycle at 200 N and 6 mm pitch is max� 60 %
The duty cycles are valid for operation within an ambient temperature of +5 °C to +40 °C
• Storage temperature: -40 °C to + 105 °C
• Noise level: With standard motor: 55-57 dB (A)
Measuring method DS/EN ISO 3743-1, actuator not loaded
