Actuator with IC (without Endstop Signal out)
Connection diagram
Fig� 9: 12xDxx-xxxxxxx8
9
2019 © LINAK A/S
IC (without endstop signal)
12XDXX-XXXXXXX8
Please be aware that if the power supply is not properly connected, you might damage the actuator!
BROWN
BLUE
BLACK
RED
INWARDS
OUTWARDS
M
H-Bridge
2 2
1 1
3
4
3
4
DEUTSCH AMP
Please be aware that if the power supply is not properly connected, you might damage the actu-
ator!
