LA12| 33
Ordering example
12 X X XX - X XXX XX X X
IC options: Basic IC
LA12 actuator:
Type 12
12 = LA12
Back fixture option X
and position 1 = Plastic position 01
2 = Plastic position 02
3 = Aluminium / 012095 Position 01
4 = Aluminium / 012095 Position 02
5 = Stainless steel (AISI 304) / 012114 position 01
6 = Stainless steel (AISI 304) / 012114 position 02
X = Special
*IC options for LA12 Necessary cable type
T = Potentiometer 0-10 V / max� 100 mm stroke 8 for IC (8 core)
D = None (no EOS out) 8 for IC (8 core)
F = Analogue feedback 0-10 V 8 for IC (8 core)
S = Single Hall feedback 8 for IC (8 core)
K = Analogue feedback 0�5-4�5 V 8 for IC (8 core)
L = Hall sensor 2 pulses/spindle revolution, 4 pole magnet 8 for IC (8 core)
N = Hall sensor 4 pulses/spindle revolution, 8 pole magnet 8 for IC (8 core)
Memory X
positioning 0 = None 0 or 1
B = Analogue feedback 0-10 V 0 (5 core)
C = Analogue feedback 0�5-4�5 V 0 (5 core)
E = Reed switch 10 pulses/spindle revolution 4 (4 core)
M = Reed switch 4 pulses/spindle revolution 4 (4 core)
P = Potentiometer max� 100 mm stroke 0 (5 core)
R = Reed switch 4 pulses/spindle revolution 2 or 3 (3 core)
Material XX
00 = Plastic inner tube
02 = Stainless steel inner tube and stainless steel eye
(AISI 303) / 031923 with bushes
03 = Stainless steel inner tube and stainless steel eye
(AISI 304) / 0301244 with bushes
Spindle type X
1 = 2 mm
2 = 4 mm
3 = 6 mm
Stroke XXX = mm
min� 019 mm; max� 130 mm (in steps of 1 mm)
Recommended versions: 040, 070, 100 and 130
Motor XX
12 = 12 V DC
24 = 24 V DC
IP version X
0 = IPX1
2 = IP66
