Linak LA12

LA12| 16
Actuator with Reed - Relative positioning 4 wires
I/O specifications
Black Reed output: same as input voltage
4 pole magnet (Option M)
2 mm pitch = 0�5 mm per
count
4 mm pitch = 1�0 mm per count
6 mm pitch = 1�5 mm per count
10 pole magnet (Option E)
2 mm pitch = 0�2 mm per
count
4 mm pitch = 0�4 mm per count
6 mm pitch = 0�6 mm per count
Max� switching capacity 750 mA
White Signal power supply (+) 12-24 V DC
